Shape Measuring Equipment

For accurate, high speed and non-destructive 3D measurements using laser technology

Inspection (CONFIDENTIAL SAFE).png
  • High accuracy measurements at +/- 0.01” (0.3 mm)

  • Resolution +/- 0.004” (0.1 mm)

  • Part to CAD comparison

  • Assess the shape of weld beads

  • Utilizes non-contact triangulation to obtain measurements

  • Class 2 laser with CCD camera

  • Designed and manufactured according to your specifications
